Audio menu

Main menu Sub-menu Function

Default

setting

Audio Audio Input Sets the audio input port from Audio 1, Audio 2 or USB

to match the current video source.

Depends on

connection

Volume Adjusts the volume. 15

Treble Adjusts the treble setting. Median

value (0)

Bass Adjusts the bass setting. Median

value (0)

Reset Resets all adjustment values for the Audio menu

functions to their default settings.

• Press the button to display the confirmation

screen, and select Ye s .

• Select Reset All to return all menu settings to their

default settings. (P.74)
